LM가이드 SNR/SNS-R형

▶LM GUIDE- SNR , SNS-R SNR , SNS-LR

SNR·SNS-R

SNR·SNS-LR

Model No.	External dimensions			LM-block dimensions
Model No.	height M	width W	length L	B	C	S×	L₁	T	K	N	N₁	E	E₁	d₀	grease nipple
SNR 25 R SNS 25 R SNR 25 LR SNS 25 LR	31	50	84 103	32	35 25	M6×8	62.4 81.6	10	25.5	7	6	10	4	3.9	B-M6F
SNR 30 R SNS 30 R SNR 30 LR SNS 30 LR	38	60	98 120.5	40	40 30	M8×10	72.1 94.6	10	31	7	7	10	6.5	3.9	B-M6F
SNR 35 R SNS 35 R SNR 35 LR SNS 35 LR	44	70	109.5 135	50	50 36	M8×12	79 104.5	12	35	8	8	9	6	5.2	B-M6F
SNR 45 R SNS 45 R SNR 45 LR SNS 45 LR	52	86	138.2 171	60	60 40	M10×17	105 137.8	15	40.4	10	8	14	8.5	5.2	B-PT1/8
SNR 55 R SNS 55 R SNR 55 LR SNS 55 LR	63	100	163.3 200.5	65	75 47.5	M12×18	123.6 160.8	18	49	11	10	13	10	5.2	B-PT1/8
SNR 65 R SNS 65 R SNR 65 LR SNS 65 LR	75	126	186 246	76	70 55	M16×20	143.6 203.6	22	60	16	15	13.5	9	8.2	B-PT1/8

※ Download CAD Files

Model No.

LM-rail dimensions

Basic load rating

Mass

width

W₁	0 -0.05

W₂

height
M₁

pitch
F

d×D×h

SNR

SNS

LM block
kg

LM rail
kg/m

C
kN

C₀
kN

C
kN

C₀
kN

SNR 25 R
SNS 25 R
SNR 25 LR
SNS 25 LR

12.5

6×9.5×8.5

31
42

79
101

26
35

61
78

0.4
0.6

3.1

SNR 30 R
SNS 30 R
SNR 30 LR
SNS 30 LR

7×11×9

49
65

106
138

40
54

81
106

0.7
0.9

4.4

SNR 35 R
SNS 35 R
SNR 35 LR
SNS 35 LR

24.5

9×14×12

63
86

144
188

52
71

110
144

1.0
1.4

6.2

SNR 45 R
SNS 45 R
SNR 45 LR
SNS 45 LR

20.5

105

14×20×17

96
126

216
288

80
105

167
222

1.9
2.4

9.8

SNR 55 R
SNS 55 R
SNR 55 LR
SNS 55 LR

23.5

36.5

120

16×23×20

131
170

292
383

109
141

225
295

3.1
4.0

14.5

SNR 65 R
SNS 65 R
SNR 65 LR
SNS 65 LR

31.5

150

18×26×22

189
260

409
572

157
216

315
441

5.6
8.0

20.5
