▶LM GUIDE RHS-ZM






Model No.

External
dimensions

LM-block dimensions

LM-rail dimensions

Basic load rating

Static permissible
moment

M

W

L

B

C

S×

L1

T

K

N

E

W1

W2

M1

F

d1×d2×h

C
kN

C0
kN

MA
N·m

MB
N·m

MC
N·m

RSH7ZM

8

17

23.4

12

8

M2×2.5

13.2

3.7

6.5

1.6

-

7

 0
-0.02

5

4.7

15

2.4×4.2×2.3

0.88

1.37

2.55

2.55

5.1

RSH9ZM

10

20

30.8

15

10

M3×2.8

19.4

4.7

7.8

2.4

-

9

 0
-0.02

5.5

5.5

20

3.5×6×3.3

1.47

2.25

5.10

5.10

10.4

RSH12ZM

13

27

35

20

15

M3×3.2

20.4

4.8

10.6

3.1

-

12

 0
-0.025

7.5

7.5

25

3.5×6×4.5

2.65

4.02

8.04

8.72

14.7

RSH15ZM

16

32

43

25

20

M3×3.5

26.5

5.8

12.6

2.9

3.6

15

 0
-0.025

8.5

9.5

40

3.5×6×4.5

4.41

6.57

16.5

17.9

30.2

          ※ Download CAD Files



▶LM GUIDE RHS-WZM





Model No.

External
dimensions

LM-block dimensions

LM-rail dimensions

Basic load rating

Static permissible
moment

M

W

L

B

C

S×

L1

T

K

N

E

W1

W2

W3

M1

F

d1×d2×h

C
kN

C0
kN

MA
N·m

MB
N·m

MC
N·m

RSH 7 WZM

9

25

31.5

19

10

M3×2.5

19.7

4.0

7.0

1.8

-

14

 0
-0.05

5.5

-

5.2

30

3.5×6×3.2

1.37

2.16

5.39

5.39

15.2

RSH 9 WZM

12

30

39

21

12

M3×2.8

27

4.5

9.1

2.3

-

18

 0
-0.05

6

-

7.5

30

3.5×6×4.5

2.45

3.92

16.3

16.3

36.0

RSH 12 WZM

14

40

44.5

28

15

M3×3.6

29.3

4.8

10.6

3

-

24

 0
-0.05

8

-

8.5

40

4.5×8×4.5

4.02

6.08

17.2

18.6

47.6

RSH 15 WZM

16

60

55.5

45

20

M4×4.5

39.3

5.7

12.6

3

3.6

42

 0
-0.05

9

23

9.5

40

4.5×8×4.5

6.66

9.80

35.2

38.2

137.0

          ※ Download CAD Files
